SRAM code r 2018 User Manual

9Caliper Piston Removal
Caliper Piston Removal
NOTICE
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (e.g. your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
Install the pad retention bolt.
Insert the pad spreader so that it snaps onto the pad retention bolt.
Squeeze the brake lever repeatedly to advance the pistons, and stop
when they contact the pad spreader.
Remove the caliper, mounting bolts, and hardware.
1
2.5 mm 15 mm Thru Axle
Pad Spreader Tool
2
3
T25 or 5 mm Torque Spec 22 mm
