25Piston Assembly Installation
Apply a small amount of Loctite® Blue 242® onto the SwingLink™ pinch
bolt.
Tighten the SwingLink pinch bolt.
Loctite Blue 242 15 mm Thru Axle
T8 QR
10
11
T8 1.1-1.3 Nm (10-12 in-lbs) 22 mm
