SRAM code r 2018 User Manual

28Lever Blade Installation
Install each reservoir cap bolt, then tighten.
Cut the hose to install a new barb and compression fitting.
Apply DOT grease to the hose barb threads. Thread the hose barb into
the hose until it is flush with the end of the hose.
NOTICE
Do not overtighten the hose barb. Overtightening may cause damage
to the hose liner.
Install the compression nut onto the hose.
T10 1.1-1.3 Nm (10-12 in-lbs) 22 mm
8
SRAM Hydraulic Hose Cutter 2.7 - 3.2 Nm (24-28 in-lbs) 22 mm
9
10
T8 DOT Grease
T8
11
