SRAM code rsc 2018 User Manual

33Lever Blade Removal
Push out the pivot pin.
Remove the lever blade.
The R lever blade has four pieces; the lever blade, the cam/push rod
assembly, a washer, and the lever return spring. To hold all pieces
together, reinstall the lever pivot pin and gently set aside.
T8 Torque Spec 22 mm
9
