SRAM code rsc 2018 User Manual

34Piston Assembly Removal
Piston Assembly Removal
NOTICE
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (e.g. your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
Remove the lever blade bushings.
Place the tips of the pliers into the eyelets of the snap ring, then
squeeze the pliers to remove the snap ring.
Remove the washer.
Pick Torque Spec 22 mm
1
Internal Snap Ring Pliers Torque Spec 22 mm
2 2
3
