32Lever Blade Installation
Lever Blade Installation
TLM/TL: Insert the lever spring and bushing into the lever blade so that
one end of the spring is braced against the lever blade and the other
extended beyond the blade.
Hold the spring and bushing in place throughout the lever installation
process.
Insert the push rod into the piston that is inside the lever body.
Insert the hooked end of the spring into the spring hole in the lever
body.
1
2
3
