St George CC29/E - Cabinet Installation Instructions; Measurements; Preparing the Cupboard Cavity

CABINET
INSTALLATION
INSTRUCTIONS
6.
CABINET
INSTALLATION
INSTRUCTIONS
Your safety
and
the proper
care
of your
appliance
is extremely
important.
Incorrect
installation
of the
appliance
as a result
of not
following
the detailed
specifications
can
affect
the appliances
performance.
Appliances
incorrectly
installed
may
invalidate
the warranty
and we strongly
recommend
that
the cavity,
venting,
wiring
and gas
connections
be
prepared
as described
in
the specifications.
This
is critical
to
appearance,
performance
and
safety.
WARNING:
Installation
must
comply
with Standards
Australia
(within
Australia)
Wiring
Rules
as well
as your local
electrical
and building
codes
and
regulations
and any
other
applicable
requirements.
Your appliance
must be properly
installed
and
grounded
by a
qualified
technician.
This appliance
must be
installed
according
to the
installation
requirements
of
the local
gas authority
and
the
appropriate
installation
code
issued
by the
A.L.P.G.A
and A.G.A
(reference
code
AG601)
and the
building
authorities
requirements
and
any other
applicable
requirements.
6.1
Measurements
Unless
otherwise
noted,
all
dimensions
provided
are in
millimetres
(mm).
The sizes
allow for
only a
small degree
of
error so
all cut outs
must
be precise
and square.
To
ensure the
cabinetry
is well
finished
the cut
edges must
also
be square
and
care taken
to ensure
the cut
edges
are free
of chips.
6.2
Preparing
the
Cupboard
Cavity
Determine
the
position
the appliance
is
to be installed,
ensuring
no structural
members
interfere
with
the space
requirements
for
the unit
and the
gas and/or
electrical
connections.
Refer to
the installation
diagrams
and Required
Clearances
for the
various mounting
options
and necessary
clearances
applicable.
