CONTENTS
6. CABINET INSTALLATION INSTRUCTIONS
6.1 Measurements........................................................................................................ 19
6.2 Preparing the
Cupboard Cavity .................................................................................... 19
6.3 Barrier Installation (CC and CB Models) ........................................................................... 22
6.4 Required Clearances ................................................................................................ 23
6.5 Securing the Cooktop................................................................................................
24
7. GAS CONNECTION INSTRUCTIONS (CG Models)
7.1 Gas Supply Connection............................................................................................. 25
7.2 Injector Sizes
for Gas Cooktops ................................................................................... 26
8. ELECTRICAL CONNECTION INSTRUCTIONS
8.1 Wiring Rules and Warnings ......................................................................................... 27
8.2 Voltage Supply Connection.........................................................................................
27
8.3 Electrical Loads...................................................................................................... 28
9. SERVICING AND MINOR ADJUSTMENTS
9.1 Setting Gas Pressure................................................................................................ 29
9.2 Gas Simmer Flame Adjustment .................................................................................... 29
9.3 Lubricating Gas Valves.............................................................................................. 30
