ST10 firmware UM0289

22/29

where:

u(n): is the output at time n (related to the duty cycle sent to driver)

P, I, D: are respectively proportional gain, integrational gain and derivative gain.

e : is the error (in terms of encoder pulses)

T : is the sample time
