ST eMotion User Manual

Hardware UM0289
8/29
eMotion kit can manage the evaluation board based on DMOS full bridge ICs
(L6205,L6206,L6207).
Figure 4. Eval 6205N board
Refer to Section 5.1.2: Board configuration on page 23 for a description of the board
configuration using eMotion.
2.2.2 L6235 Eval board (BLDC Motor)
(refer to application note AN1625 and the L6235 datasheet for more details)
eMotion kit can manage the evaluation board based on L6235 three phase brushless DC
motor.
Figure 5. Eval 6235 board
Refer to Section 5.1.2: Board configuration on page 23 for a description of the board
configuration using eMotion.
