Overview UM0289
4/29
Encoder feedback signals are directly managed by the ST10F276 through its dedicated
peripherals.
In order to guarantee an optimum quality of encoder waveforms, a special adapter is
included to shield the signals and to avoid interference (refer to Section 2.3 on page 9 for
further information).
