UM2819

UM2819 - Rev 1

page 3/37

Ordering information

2 Ordering information

To order the NUCLEO-WB55RG Nucleo-64 board, refer to Table 1. Additional information is available from the

datasheet and reference manual of the target STM32.

Table 1. Ordering information

Order code

Board reference

Target STM32

NUCLEO-WB55RG

MB1355

STM32WB55RG

2.1 Codification

The meaning of the codification is explained in Table 2.

Table 2. Codification explanation

NUCLEO-XXRYTZ

Description

Example: NUCLEO-WB55RG

MCU series in STM32 32-bit Arm Cortex MCUs

Wireless Bluetooth

STM32WB Series

Product line in the Series

STM32WBx5 product line

Product‑specific in the product line:

• 1: Die 1, full set of features

STM32WB55 MCU family

STM32 package pin count:

• R for 68 pins

68‑pin package

STM32 Flash memory size:

• G for 1 Mbytes

1‑Mbyte Flash memory
