Pin number GPIO port Signal or label Comment
M7 PC5 RMII_RXD1 -
E14 PC6 LCD_HSYNC -
D15 PC7 LCD_G6 -
D14 PC8 SDIO1_D0 -
E13 PC9 SDIO1_D1 -
C12 PC10 SDIO1_D2 -
C11 PC11 SDIO1_D3 -
B11 PC12 SDIO1_CK -
C1 PC13 WAKEUP -
D2 PC14-OSC32_IN OSC32_IN -
D1 PC15-OSC32_OUT OSC32_OUT -
C10 PD0 LCD_B1 -
A10 PD1 DETECTn -
B10 PD2 SDIO1_CMD -
A9 PD3 LCD_G7 -
C9 PD4 OCSPI1_IO4 -
B9 PD5 OCSPI1_IO5 -
D9 PD6 LCD_B2 -
B8 PD7 OCSPI1_IO7 -
L14 PD8 T_VCP_TX USART3_TX
K13 PD9 T_VCP_RX USART3_RX
L13 PD10 LCD_DISP -
J13 PD11 OCSPI1_IO0 -
J15 PD12 OCSPI1_IO1 -
H15 PD13 OCSPI1_IO3 -
H14 PD14 STMOD#14-PWM -
J12 PD15 ARD_D6 TIM4_CH4
B4 PE0 LCD_R0 -
C4 PE1 LCD_R6 -
C3 PE2 OCSPI1_IO2 -
B2 PE3 ARD_D8 -
B1 PE4 SAI4_D2 -
D3 PE5 SAI4_CK2 -
E3 PE6 SAI1_SD_A -
P9 PE7 STMOD#17 IO II DFSDM1_DATIN2
N8 PE8 Audio_Int -
R11 PE9 STMOD#18 IO II DFSDM1_CKOUT
R9 PE10 STMOD#19 IO II DFSDM1_DATIN4
R12 PE11 LCD_G3 -
P12 PE12 LCD_B4 -
UM2679
STM32H735G-DK I/O assignment
UM2679 - Rev 1
page 31/42
