Appendix A STM32H735G-DK I/O assignment
Table 24. STM32H735G-DK I/O assignment
Pin number GPIO port Signal or label Comment
P1 PA0 ARD_D3 TIM5_CH1
P2 PA1 RMII_REF_CLK -
R2 PA2 RMII_MDIO -
N5 PA3 LCD_B5 -
P5 PA4 LCD_VSYNC -
P6 PA5 STMOD#13-ADC ADC12_INP19 II DAC1_OUT2
R7 PA6 LCD_G2 -
N6 PA7 RMII_CRS_DV -
B14 PA8 LCD_B3 -
D13 PA9 USB_FS_VBUS -
C14 PA10 USB_FS_ID -
C15 PA11 USB_FS_DM -
B15 PA12 USB_FS_DP -
B13 PA13 JTMS SWDIO
A12 PA14 JTCK SWCLK
A11 PA15 JTDI -
R8 PB0 LCD_G1 -
M8 PB1 LCD_G0 -
P7 PB2 OCSPI1_DQS -
A6 PB3 JTDO/TRACESWO -
B6 PB4 NJTRST -
C6 PB5 FDCAN2_RX -
A5 PB6 FDCAN2_TX -
B5 PB7 ARD_D9 TIM4_CH2
A2 PB8 LCD_B6 -
B3 PB9 LCD_B7 -
N12 PB10 RMII_RX_ER -
P10 PB11 RMII_TX_EN -
M15 PB12 RMII_TXD0 -
L15 PB13 RMII_TXD1 -
K15 PB14 ARD_D1 USART1_TX
K14 PB15 ARD_D0 USART1_RX
L2 PC0 ARD_A0 ADC123_INP10
L3 PC1 RMII_MDC -
M1 PC2 USER_LED2 -
M2 PC3 USER_LED1 -
R6 PC4 RMII_RXD0 -
UM2679
STM32H735G-DK I/O assignment
UM2679 - Rev 1
page 30/42
