Alternate function mapping to pins AN4938

18/48 DocID029918 Rev 1

2 Alternate function mapping to pins

In order to easily explore the peripheral alternate functions mapping to the pins it is

recommended to use the STM32CubeMX tool available on http://www.st.com.

Figure 10. STM32CubeMX example screen-shot
