Item Q.ty Ref. Part/Value Description Manufacturer Order code
3 3 C49
100 nF,16 V SMD
0805
Capacitor Any Any
1 1
R71, R73, R76,
R77, R79, R80,
R82, R85
SMD 0805 Resistors Any Any
2 2 R74, R75 SMD 0805 100K Any Any
3 3 R78 220, 'SMD 0805 Resistors Any Any
4 4
R81,R83,R84,R8
7,R1
17,R70,R86
SMD 0805
Resistor (not
mounted)
Any Any
5 5 R88, R119 10 K, SMD 0805 Resistors Any Any
6 6 R116 47 K, 'SMD 0805 Resistor Any Any
1 1 D1 SMD 0805 Yellow LED Dialight 598-8150-107f
UM2667
Bill of materials
UM2667 - Rev 1
page 15/22
