OWNER’S MANUAL

Convertible Deep Well Jet Pumps

NOTICE D’UTILISATION

Pompe à éjecteur transformables

pour puits profonds

MANUAL DEL USUARIO

Bombas Convertibles tipo “Jet”

para Pozos Profundos

Installation/Operation/Parts

For further operating, installation, or

maintenance assistance:

Call 1-262-728-9181

English . . . . . . . . . . . . . . Pages 2-12

Installation/Fonctionnement/Pièces

Pour plus de renseignements

concernant l’utilisation,

l’installation ou l’entretien,

Composer le

1 (262) 728-9181

Français . . . . . . . . . . . Pages 13-23

Instalación/Operación/Piezas

Para mayor información sobre el fun-

cionamiento, instalación o

mantenimiento de la bomba:

Llame al 1-262-728-9181

Español . . . . . . . . . . .Paginas 24-34

1859 0795

S367 (Rev. 5/5/09)

293 Wright Street, Delavan, WI 53115

Questions and Answers:

K
Kendra Reese DVMAug 5, 2025
What to do if my STA-RITE Water Pump runs but no water comes out?
- I
  Isaac MortonAug 5, 2025
  First, ensure the STA-RITE Water Pump is primed by checking that the pump, suction piping, and well piping are full of water. If they aren't, fill them. In cold weather, check for frozen pipes and thaw them carefully to avoid splits. Consider heating the pump pit or pump house and burying pipes below the frost line. Other possible causes: air leaks in the suction line, dropping water level in the well, foot valve stuck or plugged, ejector plugged, impeller plugged, foot valve or strainer stuck in the mud in the bottom of the well, a shallow well pump installed on a well with more than 25 ft depth to water (in this case a deep well jet pump is needed).
L
Lucas MackAug 10, 2025
How to troubleshoot a STA-RITE ALE Water Pump motor that will not run?
- S
  Scott LaneAug 10, 2025
  Verify the disconnect switch is ON and that the circuit breaker hasn't tripped or the fuse hasn't blown. Disconnect the power and ensure that the wires connecting the motor to the power supply and pressure switch are tight and correctly connected.
L
Lynn PattersonAug 14, 2025
Why does my STA-RITE ALE Water Pump cycle too frequently?
- D
  David BeardAug 14, 2025
  First, check that no faucets are left open. If your system uses a standard tank, ensure it isn't waterlogged; if it is, drain it to the air volume control level. Verify the AVC functions correctly and that all connections are leak-free. For precharged tanks, disconnect power, open all faucets, and bleed the tank pressure. Use a tire gauge to check the air pressure; it should be 2 PSI lower than the pressure switch's cut-in setting (e.g., 28 PSI if the switch starts at 30 PSI). Check the air valve for leaks using a soap solution and replace the core if needed.
D
Devin JonesAug 19, 2025
Why does my STA-RITE ALE motor run hot and trip the overload?
- C
  christie63Aug 19, 2025
  Verify the motor is correctly wired according to the electrical instructions. Ensure the voltage at the pump is within + 10% of the motor’s rated nameplate voltage. Disconnect the power and make sure the wires connecting the motor to the power supply are sized appropriately. If the pump is cycling too frequently, refer to Section E.
J
John TurnerAug 23, 2025
What causes a STA-RITE ALE Water Pump not to deliver water to full capacity?
- C
  chelseanewmanAug 23, 2025
  Possible causes are: the well water level is lower than estimated, making a different nozzle/venturi combination necessary; steel piping (if used) is corroded or limed, restricting capacity and increasing friction; or the piping is too small for the installation.
A
Anthony HortonAug 27, 2025
Why is there air spurting from the faucets when using my STA-RITE ALE?
- J
  Joshua HaneyAug 27, 2025
  The STA-RITE Water Pump may still be priming; once priming is complete, all air should be ejected from the system.
T
Tina MillerAug 31, 2025
What to do if STA-RITE Water Pump leaks around the clamp?
- C
  Christopher TranAug 31, 2025
  Tighten the clamp nut 1-2 turns, but be careful not to overtighten it.

STA-RITE ALE Specifications

General

Brand	STA-RITE
Model	ALE
Category	Water Pump
Language	English

Summary

Safety

Read and Follow Safety Instructions

Electrical Safety

General Safety

Electrical

Preparing to Start the Pump – Deep Well

Fill Pump

Prime Pump

Set Control Valve

Preparing to Start the Pump – Shallow Well

Open Control Valve

Troubleshooting

Motor Will Not Run

Diagnosing why the motor fails to start, checking power and wiring.

Motor Runs Hot and Overload Trips

Troubleshooting motor overheating and overload trip issues.

Motor Runs but No Water is Delivered

Identifying causes for no water delivery, including priming and freezing.

Pump Does Not Deliver Water to Full Capacity

Addressing issues of reduced water delivery and system friction.

Pump Cycles Too Frequently or Does Not Shut Off

Resolving frequent pump cycling or failure to shut off.

Air Spurts from Faucets

Explaining air spurts during priming and potential system leaks.

Pump Leaks Around Clamp

Instructions for tightening clamp nuts to resolve leaks.
