STA-RITE ALE - Typical Installations

STA-RITE
STA-RITE
STA-RITE
STA-RITE
Drive Pipe
sends water
down the well
to drive water
up through the
Suction Pipe
to Pump Suction
Drive
over
Suction
Suction
over
Drive
Piping omitted
for clarity
Discharge
819 0495
STA-RITE
STA-RITE
Suction
(Larger)
Pipe
Well
Head
If well head and pump
don't match, use a
reversing adapter or
twist reinforced flexible
pipe to connect pump
to well head.
Drive
(Smaller)
Pipe
328 0395
Tap clamp
to seat it
STA-RITE
STA-RITE
STA-RITE
STA-RITE
Install venturi
in larger port
in front
of pump.
820 0495
Figure 1: Drive and Suction Functions
Figure 2: Reversed Connections
to Well
Figure 3: Mount Ejector –
Shallow Well
Typical Installations 4
To Household
Water System
Priming
Tee and
Plug
Drive
Coupling
Drive
Point
Check
Valve
Not
to
Scale
Relief Valve
Pressure Gauge
and Priming Port
Drive point
below water
level
Drive
Point
Pre-Charged
Tank
Built-in
Check
Valve
1837 0695
Priming
Tee and
Plug
Well
Casing
Foot
Valve
Sanitary
Well Seal
Suction Pipe
From Well
Foot
Valve
Screen
10'
Min.
5–10'
Cased
Well
Open
Water
Strainer
1836 0695
Figure 5:Typical Shallow Well Installations
To Household
Water System
Pressure
Switch
Suction Pipe
From Well
Air Volume
Control
Air Volume
Control Tube
Priming Tee
and Plug
Relief Valve
Drive Pipe
To Well
Standard
Tank
1835 0695
Venturi
Suction (Larger)
Pipe from Well
Well
Head
Drive
(Smaller)
Pipe to
Well
Nozzle
Ejector
Foot Valve
Strainer
4
1
JET NO.
J32P-
24
Well Casing
serves as
Drive Pipe
Leather
Cup Seals
"Double Pipe"
(4" and Larger
Diameter Well)
"Single Pipe"
(2" and 3"
Diameter Well)
1834 0695
Figure 4:Typical Deep Well Installations
