ASSEMBLY INSTRUCTIONS
8
all packing materials from your area and place them back into the box. Do not dispose of the packing
materials until assembly is completed. Read each step carefully before beginning. If you are missing
a part, please go to staminaproducts.com under the Customer Care section and order the part
needed, e-mail us at customer.care@staminaproducts.com, or call us toll free at 1-800-375-7520
Time) Monday through Thursday and 8:00 A.M. to 3:00 P.M. (Central Time) on Friday.
Some product parts are t tested at the factory to ensure proper t and alignment. Marks in
the paint may be noticeable, but are not an indication of damage.
NOTE: DO NOT SECURELY TIGHTEN ALL BOLTS UNTIL STEP 3.
STEP 1
Attach the LOWER UPRIGHTS(7) to the BASE FRAME(6) with BUTTON HEAD BOLTS(M6x1x20mm)
(46) and ARC WASHERS(M6)(45).
To Next Page
