Stamina Precision Series - Operational Instructions; Using the Push-Thru Bar; Using the Extension Cushion

TO USE THE ACCESSORIES:
NOTE: Prior to adding the PUSH-THRU SPRING(19) to the PUSH-THRU BAR(27) make sure the SAFETY
CHAIN(25) is at a length that allows enough clearance to get under the PUSH-THRU BAR(27).
PUSH-THRU BAR
When doing exercises that require the spring resistance to come from above the bar, attach the PUSH-THRU
SPRING(19) to the hook on the upper side of the PUSH-THRU BAR(27) with the DOUBLE ENDED CLIP
(23). Attach the other end of the PUSH-THRU SPRING(19) to one of the eyehooks on the UPRIGHT(9)
with the LINK(24). When doing exercises that require the spring resistance to come from below the bar,
attach the PUSH-THRU SPRING(19) to the hook on the underside of the PUSH-THRU BAR(27) with the
DOUBLE ENDED CLIP(23). Attach the other end of the PUSH-THRU SPRING(19) to one of the eyehooks
on the LOWER UPRIGHT(7) with the LINK(24). Be sure that the SAFETY CHAIN(25) is always connected
to the PUSH-THRU BAR(27) when in use.
!
CAUTION
When using the PUSH-THRU SPRING(19) from below, you must hook the spring onto the
LOWER UPRIGHT(7) with the LINK(24) and make sure the SAFETY CHAIN(25) is connected. Ensure
that the SPRING SLEEVE(16) which covers the PUSH-THRU SPRING(19) is moved over the lower part
of the spring to avoid pulling the user’s hair or clothing.
13
EXTENSION CUSHION
󰀨exercises, you can place the
EXTENSION CUSHION(5) at the front of the CUSHIONS(3), or at the
back, inside the BASE FRAME(6).
OPERATIONAL INSTRUCTIONS
Place the Extension
Cushion(5) here for
some exercises.
