CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a
10° TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage 35 40 Liquid Suction
BCHY0100C KAJA-011E-TAC KAJA-011E-TAC 7650 8500 R134a B 1 3/8 5/8 8 208-230/60/3
BCHY0150C KALA-016E-TAC KALA-016E-TAC 10800 12000 R134a C 1.5 1/2 7/8 13 208-230/60/3
BCHY0150CC KALA-016E-TAC KALA-016E-TAC 10800 12000 R134a C 1.5 1/2 7/8 13 208-230/60/3
BCHY0150E KALA-016E-TAD KALA-016E-TAD 9000 10000 R134a C 1.5 7/8 1 1/8 6 460/60/3
BCHY0150G KALA-016E-TAD KALA-016E-TAD 9000 10000 R134a C 1.5 7/8 1 1/8 6 380-420/50/3
BCHY0200C EAVA-021E-TAC EAVA-021E-TAC 16200 18000 R134a C 2 1/2 7/8 13 208-230/60/3
BCHY0200CC EAVA-021E-TAC EAVA-021E-TAC 16200 18000 R134a C 2 1/2 7/8 13 208-230/60/3
BCHY0300B 2DF3-030E-CFB 2DF3-030E-CFB 32902 36558 R134a C 3 7/8 1 1/8 36 230/60/1
BCHY0300C 2DF3-030E-TFC 2DF3-030E-TFC 32902 36558 R134a C 3 7/8 1 1/8 23 208-230/60/3
BCHY0300E 2DF3-030E-TFD 2DF3-030E-TFD 32902 36558 R134a C 3 7/8 1 1/8 13 460/60/3
BCHY0300G 2DF3-030E-TFD 2DF3-030E-TFD 27419 30465 R134a C 3 7/8 1 1/8 13 380-420/50/3
BCHY0600C 2DB3-060E-TFC 2DB3-060E-TFC 44543 49492 R134a C 6 7/8 1 3/8 41 208-230/60/3
BCHY060XC 3DA3-060E-TFC 3DA3-060E-TFC 53212 59124 R134a D 6 7/8 1 3/8 43 208-230/60/3
BCHY0750C 3DB3-075E-TFC 3DB3-075E-TFC 63039 70043 R134a E 7.5 1 1/8 1 3/8 46 208-230/60/3
BCHY1000C 3DS3-100E-TFC 3DS3-100E-TFC 102088 113431 R134a F 10 7/8 1 3/8 64 208-230/60/3
BCHY100XCC 3DS3-100E-TFC 3DS3-100E-TFC 102088 113431 R134a F 10 7/8 1 3/8 64 208-230/60/3
BCHZ0100C EJAM-A100-TAC KARA-010E-TAC 8064 8960 R-404A A 1 3/8 5/8 7 208-230/60/3
BCHZ0200C ERCA-021E-TAC ERCA-021E-TAC 17402 19335 R-404A C 2 1/2 7/8 15 208-230/60/3
BCHZ0200CC ERCA-021E-TAC ERCA-021E-TAC 17402 19335 R-404A C 2 1/2 7/8 15 208-230/60/3
BCHZ0300C ERFA-031E-TAC ERFA-031E-TAC 24604 27338 R-404A C 3 5/8 1 1/8 19 208-230/60/3
BCHZ0300CC ERFA-031E-TAC ERFA-031E-TAC 24604 27338 R-404A C 3 5/8 1 1/8 19 208-230/60/3
BCHZ0500C 2DC3-050E-TFC 2DC3-050E-TFC 41437 46041 R-404A C 5 5/8 1 3/8 34 208-230/60/3
BCHZ0500E 2DC3-050E-TFD 2DC3-050E-TFD 41437 46041 R-404A C 5 5/8 1 3/8 16 460/60/3
BCHZ0750C 2DA3-075E-TFC 2DA3-075E-TFC 70912 78791 R-404A E 7.5 5/8 1 3/8 47 208-230/60/3
BCHZ0750CC 2DA3-075E-TFC 2DA3-075E-TFC 70912 78791 R-404A E 7.5 5/8 1 3/8 47 208-230/60/3
BCHZ0750E 2DA3-075E-TFD 2DA3-075E-TFD 70912 78791 R-404A E 7.5 5/8 1 3/8 21 460/60/3
BCHZ1000C 3DS3-100E-TFC 3DS3-100E-TFC 101031 112257 R-404A F 10 7/8 1 3/8 64 208-230/60/3
BCHZ1000E 3DB3-100E-TFD 3DB3-100E-TFD 101031 112257 R-404A F 10 7/8 1 3/8 30 460/60/3
BCHZ1500C 3DS3-150E-TFC 3DS3-150E-TFC 128315 142572 R-404A F 15 7/8 1 5/8 84 208-230/60/3
BCHZ1500E 3DS3-150E-TFD 3DS3-150E-TFD 128315 142572 R-404A F 15 7/8 1 5/8 42 460/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
