Standex MHHX030CCC - Condensing Unit Specifications

5/16 Rev. B 57-02497 39
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond
Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At Room
Temp. With a 10° TD, 90°
Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage 20 30 35 40 Liquid Suction
MSHX0201B ZB15KCE-PFV ZB15KCE-PFV 14539 17930 19707 21647 R-22 M2 2 1/2 7/8 26 200-230/60/1
MSHX0201C ZB15KCE-TF5 ZB15KCE-TF5 14348 18294 20171 22091 R-22 M2 2 1/2 7/8 19 200-230/60/3
MSHX0231B ZB19KCE-PFV ZB19KCE-PFV 17844 20399 22398 24530 R-22 M2 2.5 1/2 7/8 28 200-230/60/1
MSHX0231C ZB19KCE-TF5 ZB19KCE-TF5 17612 20310 22310 24443 R-22 M2 2.5 1/2 7/8 19 200-230/60/3
MSHX0301B ZB21KCE-PFV ZB21KCE-PFV 21761 24088 26672 29241 R-22 M3 3 5/8 7/8 35 200-230/60/1
MSHX0301C ZB21KCE-TF5 ZB21KCE-TF5 21671 24233 27078 29882 R-22 M3 3 5/8 7/8 26 200-230/60/3
MSHX0341B ZB26KCE-PFV ZB26KCE-PFV 24911 27227 30294 33317 R-22 M3 4 5/8 1 1/8 39 200-230/60/1
MSHX0341C ZB26KCE-TF5 ZB26KCE-TF5 24823 28057 31058 34041 R-22 M3 4 5/8 1 1/8 38 200-230/60/3
MSHX0401B ZB30KCE-PFV ZB30KCE-PFV 29390 32162 35707 39175 R-22 M5 4 1/2 7/8 43 200-230/60/1
MSHX0401C ZB30KCE-TF5 ZB30KCE-TF5 25338 32300 35805 39263 R-22 M5 4 5/8 1 1/8 38 200-230/60/3
MSHX0501B ZB38KCE-PFV ZB38KCE-PFV 35621 36112 40687 45202 R-22 M5 5 5/8 1 1/8 48 200-230/60/1
MSHX0501C ZB38KCE-TF5 ZB38KCE-TF5 35770 38821 42975 47075 R-22 M5 5 5/8 1 1/8 44 200-230/60/3
MSHX0571C ZB45KCE-TF5 ZB45KCE-TF5 35847 45243 49929 54638 R-22 M5 6 5/8 1 1/8 44 200-230/60/3
MSHZ0201B ZB15KCE-PFV ZB15KCE-PFV 14539 17312 18932 20530 R-404a M2 2 1/2 7/8 26 200-230/60/1
MSHZ0201C ZB15KCE-TF5 ZB15KCE-TF5 14348 17182 18897 20577 R-404a M2 2 1/2 7/8 19 200-230/60/3
MSHZ0251B ZB19KCE-PFV ZB19KCE-PFV 17844 20947 22870 24757 R-404a M2 2.5 1/2 7/8 28 200-230/60/1
MSHZ0251C ZB19KCE-TF5 ZB19KCE-TF5 17612 20779 22704 24593 R-404a M2 2.5 1/2 7/8 19 200-230/60/3
MSHZ0301B ZB21KCE-PFV ZB21KCE-PFV 21761 25734 28162 30561 R-404a M3 3 5/8 7/8 35 200-230/60/1
MSHZ0301C ZB21KCE-TF5 ZB21KCE-TF5 21671 25647 28076 30475 R-404a M3 3 5/8 7/8 26 200-230/60/3
MSHZ0351B ZB26KCE-PFV ZB26KCE-PFV 24911 29464 32205 34892 R-404a M3 4 5/8 1 1/8 39 200-230/60/1
MSHZ0351C ZB26KCE-TF5 ZB26KCE-TF5 24823 29294 32038 34727 R-404a M3 4 5/8 1 1/8 38 200-230/60/3
MSHZ0401B ZB30KCE-PFV ZB30KCE-PFV 29390 35061 38505 41905 R-404a M5 4 1/2 7/8 43 200-230/60/1
MSHZ0401C ZB30KCE-TF5 ZB30KCE-TF5 29299 34914 38238 41519 R-404a M5 4 1/2 7/8 38 200-230/60/3
MSHZ0501B ZB38KCE-PFV ZB38KCE-PFV 35621 42516 46519 50477 R-404a M5 5 5/8 1 1/8 48 200-230/60/1
MSHZ0501C ZB38KCE-TF5 ZB38KCE-TF5 35770 42309 46293 50208 R-404a M5 5 5/8 1 1/8 44 200-230/60/3
MSHZ0581C ZB45KCE-TF5 ZB45KCE-TF5 41789 48996 53473 57879 R-404A M5 6 5/8 1 1/8 44 200-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a 10°
TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41)
H.P.
Connections
MCA Voltage -20 -10 0 Liquid Suction
MSLZ0071B ZF06K4E-PFV ZF06K4E-PFV 5764 7165 8680 R-404A M1 2 3/8 7/8 21 208-230/60/1
MSLZ0071C ZF06K4E-TF5 ZF06K4E-TF5 5764 7165 8680 R-404A M1 2 3/8 7/8 16 200-230/60/3
MSLZ0071FB ZF06K4E-PFV ZF06K4E-PFV 5764 7165 8680 R-404A M1 2 3/8 7/8 21 208-230/60/1
MSLZ007FB ZF06K4E-PFV ZF06K4E-PFV 5994 7535 9250 R-404A S 2 3/8 7/8 22 208-230/60/1
MSLZ0101B ZF09K4E-PFV ZF09K4E-PFV 8537 10653 12980 R-404A M2 3 3/8 7/8 27 208-230/60/1
MSLZ0101C ZF09K4E-TF5 ZF09K4E-TF5 8537 10653 12980 R-404A M2 3 3/8 7/8 20 200-230/60/3
MSLZ0151B ZF13K4E-PFV ZF13K4E-PFV 11729 14994 18532 R-404A M3 4 1/2 7/8 43 208-230/60/1
MSLZ0151C ZF13K4E-TF5 ZF13K4E-TF5 11729 14994 18532 R-404A M3 4 1/2 7/8 32 200-230/60/3
MSLZ0181B ZF15K4E-PFV ZF15K4E-PFV 15159 18970 23294 R-404A M3 5 1/2 1 1/8 49 208-230/60/1
MSLZ0181C ZF15K4E-TF5 ZF15K4E-TF5 15082 18945 23335 R-404A M3 5 1/2 1 1/8 36 200-230/60/3
MSLZ0161C ZF15K4E-TF5 ZF15K4E-TF5 15082 18945 23335 R-404A M5 5 5/8 1 1/8 38 200-230/60/3
MSLZ0221C ZF18K4E-TF5 ZF18K4E-TF5 18191 23018 28448 R-404A M5 6 1/2 1 1/8 39 200-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
