5/16 Rev. B 57-02497 38
MHHZ0501B CS33K6E-PFV CS33K6E-PFV 30884 39545 44031 48868 R-404A
M5 5 5/8 1 3/8 44 208-230/60/1
MHHZ0501BM
CS33K6E-PFV CS33K6E-PFV 30884 39545 44031 48868 R-404A
M5 5 5/8 1 3/8 44 208-230/60/1
MHHZ0501C CS33K6E-TF5 CS33K6E-TF5 30487 39036 43433 48384 R-404A
M5 5 5/8 1 3/8 44 200-230/60/3
MHHZ0501CM
CS33K6E-TF5 CS33K6E-TF5 30487 39036 43433 48384 R-404A
M5 5 5/8 1 3/8 44 200-230/60/3
MHHZ050CC CS33K6E-TF5 CS33K6E-TF5 30487 39036 43433 48384 R-404A
M5 5 5/8 1 3/8 24.7 200-230/60/3
MHHXT181C AWG5520EXT AWG5520EXT 11120 14238 16188 18137 R-22 M2 1.5 3/8 7/8 23 200-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond
Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a 10°
TD, 90° Ambient
Ref.
Size
(See
pp.
39-41)
H.P.
Connections
MCA
Voltage -20 -10
0
Liquid Suction
MHLZ0021B AFT22C1E-CFV AFT22C1E-CFV 1702 2210 2784 R-404A
M1 .5 3/8 5/8 13 208-230/60/1
MHLZ0031B AFT29C1E-CFV AFT29C1E-CFV 2276 2956 3881 R-404A
M1 .75 3/8 5/8 13 208-230/60/1
MHLZ0051B CF04K6E-PFV CF04K6E-PFV 2509 3945 5466 R-404A
M1 1 3/8 7/8 16 208-230/60/1
MHLZ0051C CF04K6E-TF5 CF04K6E-TF5 2495 3769 5267 R-404A
M1 1 3/8 7/8 13 200-230/60/3
MHLZ0051TB CF04K6E-PFV CF04K6E-PFV 2509 3945 5466 R-404A
M1 1 3/8 7/8 16 208-230/60/1
MHLZ005TB CF04K6E-PFV CF04K6E-PFV 2629 4207 5934 R-404A
S 1 3/8 7/8 17 208-230/60/1
MHLZ0071B CF06K6E-PFV CF06K6E-PFV 4032 5938 7988 R-404A
M1 1.5 3/8 1 1/8 18 208-230/60/1
MHLZ0071BQ CF06K6E-PFV CF06K6E-PFV 4032 5938 7988 R-404A
M1 1.5 3/8 1 1/8 18 208-230/60/1
MHLZ0071C CF06K6E-TF5 CF06K6E-TF5 3962 5722 7717 R-404A
M1 1.5 3/8 1 1/8 13 200-230/60/3
MHLZ0071TB CF06K6E-PFV CF06K6E-PFV 4031 5936 7988 R-404A
M1 1.5 3/8 1 1/8 18 208-230/60/1
MHLZ007TB CF06K6E-PFV CF06K6E-PFV 4270 6437 8832 R-404A
S 1.5 3/8 1 1/8 20 208-230/60/1
MHLZ0091B CF09K6E-PFV CF09K6E-PFV 6193 9133 12480 R-404A
M2 2 1/2 1 1/8 26 208-230/60/1
MHLZ0091BQ CF09K6E-PFV CF09K6E-PFV 6193 9133 12480 R-404A
M2 2 1/2 7/8 26 208-230/60/1
MHLZ0091C CF09K6E-TF5 CF09K6E-TF5 6484 9230 12314 R-404A
M2 2 1/2 7/8 19 200-230/60/3
MHLZR091C CF09K6E-TF5 CF09K6E-TF5 6484 9230 12314 R-404A
M2 2 1/2 7/8 19 200-230/60/3
MHLZ0091CQ CF09K6E-TF5 CF09K6E-TF5 6484 9230 12314 R-404A
M2 2 1/2 7/8 19 200-230/60/3
MHLZ009KC CF09K6E-TF5 CF09K6E-TF5 6800 9806 13265 R-404A
T 2 1/2 1 1/8 20 200-230/60/3
MHLZ0121B CF12K6E-PFV CF12K6E-PFV 8077 11559 15035 R-404A
M2 3 1/2 1 1/8 30 208-230/60/1
MHLZ0121C CF12K6E-TF5 CF12K6E-TF5 8402 11596 14963 R-404A
M2 3 1/2 1 1/8 21 200-230/60/3
MHLZ0121CQ CF12K6E-TF5 CF12K6E-TF5 8402 11596 14963 R-404A
M2 3 1/2 1 1/8 21 200-230/60/3
MHLZ0121KQ CF12K6E-PFV CF12K6E-PFV 8077 11559 15035 R-404A
M2 3 1/2 1 1/8 30 200-220/50/1
MHLZ012KC CF12K6E-TF5 CF12K6E-TF5 8958 12510 16365 R-404A
T 3 1/2 1 1/8 23 200-230/60/3
MHLZT051B AWA2440ZXD AWA2440ZXD 3001 3897 5433 R-404A
M1 1 3/8 7/8 15 208-230/60/1
MHLZT051C AWA2440ZXT AWA2440ZXT 2501 3809 5317 R-404A
M1 1 3/8 7/8 13 200-230/60/3
MHLZT071B AWA2460ZXD AWA2460ZXD 4208 5982 7931 R-404A
M1 1.5 3/8 1 1/8 20 208-230/60/1
MHLZT071C AWA2460ZXT AWA2460ZXT 4047 5770 7668 R-404A
M1 1.5 3/8 1 1/8 15 200-230/60/3
MHLZT091B AVA2490ZXD AVA2490ZXD 7695 9994 13424 R-404A
M2 2 1/2 1 1/8 26 208-230/60/1
MHLZT091C AVA2490ZXT AVA2490ZXT 7409 9622 12937 R-404A
M2 2 1/2 1 1/8 19 200-230/60/3
MHLZT121B AVA2512ZXN AVA2512ZXN 9053 12679 16888 R-404A
M2 2.5 1/2 1 1/8 27 208-230/60/1
MHLZT121C AVA2512ZXT AVA2512ZXT 8733 12245 16333 R-404A
M2 2.5 1/2 1 1/8 19 200-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
