5/16 Rev. B 57-02497 37
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At Room
Temp. With a 10° TD, 90°
Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage 20 30 35 40 Liquid Suction
MHHY0101C CS10K6E-TF5 CS10K6E-TF5 6084 7790 9145 10500 R-134a M2 2 1/2 7/8 20 200-230/60/3
MHHY0121C CS12K6E-TF5 CS12K6E-TF5 7263 9300 11050 12800 R-134a M2 2 1/2 7/8 20 200-230/60/3
MHHY0141C CS14K6E-TF5 CS14K6E-TF5 8591 11000 12900 14800 R-134a M2 2.5 1/2 7/8 23 200-230/60/3
MHHY0180C CS18K6E-TF5 CS18K6E-TF5 14000 16400 18800 R-134a U 2.5 1/2 7/8 28 200-230/60/3
MHHY0181C CS18K6E-TF5 CS18K6E-TF5 10934 14000 16400 18800 R-134a M3 2.5 1/2 7/8 28 200-230/60/3
MHHY0200C CS20K6E-TF5 CS20K6E-TF5 15600 18300 21000 R-134a U 3 1/2 7/8 38 200-230/60/3
MHHY0201C CS20K6E-TF5 CS20K6E-TF5 12184 15600 18300 21000 R-134a M3 3 1/2 7/8 38 200-230/60/3
MHHY0270C CS27K6E-TF5 CS27K6E-TF5 19700 23450 27200 R-134a X 4 5/8 1 1/8 45 200-230/60/3
MHHY0271C CS27K6E-TF5 CS27K6E-TF5 15386 19700 23450 27200 R-134a M5 4 5/8 1 1/8 44 200-230/60/3
MHHY0330C CS33K3E-TF5 CS33K3E-TF5 23700 28050 32400 R-134a X 5 5/8 1 1/8 45 200-230/60/3
MHHY0331C CS33K3E-TF5 CS33K3E-TF5 18510 23700 28050 32400 R-134a M5 5 5/8 1 1/8 44 200-230/60/3
MHHZ0071B RS43C2E-CAV RS43C2E-CAV 4390 5714 6454 7256 R-404A M1 .5 3/8 5/8 13 208-230/60/1
MHHZ0071BM RS43C2E-CAV RS43C2E-CAV 4390 5714 6454 7256 R-404A M1 .5 3/8 5/8 13 208-230/60/1
MHHZ0081B RS55C2E-CAV RS55C2E-CAV 5255 6557 7250 8000 R-404A M1 .75 3/8 7/8 13 208-230/60/1
MHHZ0081BM RS55C2E-CAV RS55C2E-CAV 5255 6557 7250 8000 R-404A M1 .75 3/8 7/8 13 208-230/60/1
MHHZ0111B RS70C1-PFV RS70C1E-PFV 6746 8313 9122 10041 R-404A M1 1 3/8 7/8 20 208-230/60/1
MHHZ0111BM RS70C1-PFV RS70C1E-PFV 6746 8313 9122 10041 R-404A M1 1 3/8 7/8 20 208-230/60/1
MHHZ0111C RS70C1E-TFC RS70C1E-TFC 6596 8109 8955 9829 R-404A M1 1 3/8 7/8 20 208-230/60/3
MHHZ0111CM RS70C1E-TFC RS70C1E-TFC 6596 8109 8955 9829 R-404A M1 1 3/8 7/8 20 208-230/60/3
MHHZ0171B CS10K6E-PFV CS10K6E-PFV 10222 13089 14485 15924 R-404A M2 1.5 1/2 7/8 20 208-230/60/1
MHHZ0171BM CS10K6E-PFV CS10K6E-PFV 10222 13089 14485 15924 R-404A M2 1.5 1/2 7/8 20 208-230/60/1
MHHZ0171C CS10K6E-TF5 CS10K6E-TF5 10083 12911 14326 15671 R-404A M2 1.5 1/2 7/8 20 200-230/60/3
MHHZ0171CM CS10K6E-TF5 CS10K6E-TF5 10083 12911 14326 15671 R-404A M2 1.5 1/2 7/8 20 200-230/60/3
MHHZ0191B CS12K6E-PFV CS12K6E-PFV 11579 14826 16403 18019 R-404A M2 2 1/2 1 1/8 20 208-230/60/1
MHHZ0191BM CS12K6E-PFV CS12K6E-PFV 11579 14826 16403 18019 R-404A M2 2 1/2 1 1/8 20 208-230/60/1
MHHZ0191C CS12K6E-TF5 CS12K6E-TF5 11450 14661 16248 17867 R-404A M2 2 1/2 1 1/8 19 200-230/60/3
MHHZ0191CM CS12K6E-TF5 CS12K6E-TF5 11450 14661 16248 17867 R-404A M2 2 1/2 1 1/8 19 200-230/60/3
MHHZ0221B CS14K6E-PFV CS14K6E-PFV 13063 16726 18310 19842 R-404A M2 2.5 1/2 1 1/8 23 208-230/60/1
MHHZ0221BM CS14K6E-PFV CS14K6E-PFV 13063 16726 18310 19842 R-404A M2 2.5 1/2 1 1/8 23 208-230/60/1
MHHZ0221C CS14K6E-TF5 CS14K6E-TF5 12879 16491 18085 19696 R-404A M2 2.5 1/2 1 1/8 23 200-230/60/3
MHHZ0221CM CS14K6E-TF5 CS14K6E-TF5 12879 16491 18085 19696 R-404A M2 2.5 1/2 1 1/8 23 200-230/60/3
MHHZ0251B CS16K6E-PFV CS16K6E-PFV 14751 18474 20188 21723 R-404A M2 2.75 1/2 1 1/8 23 208-230/60/1
MHHZ0251C CS16K6E-TF5 CS16K6E-TF5 14540 18211 20009 21810 R-404A M2 2.75 1/2 1 1/8 23 200-230/60/3
MHHZ0301B CS18K6E-PFV CS18K6E-PFV 18638 23556 25986 28371 R-404A M3 3.0 5/8 1 1/8 38 208-230/60/1
MHHZ0301C CS18K6E-TF5 CS18K6E-TF5 18467 23308 25618 28048 R-404A M3 3.0 5/8 1 1/8 38 200-230/60/3
MHHZ0331B CS20K6E-PFV CS20K6E-PFV 20175 25832 29007 32467 R-404A M3 3.5 5/8 1 1/8 38 208-230/60/1
MHHZ0331BM CS20K6E-PFV CS20K6E-PFV 20175 25832 29007 32467 R-404A M3 3.5 5/8 1 1/8 38 208-230/60/1
MHHZ0331C CS20K6E-TF5 CS20K6E-TF5 19890 25468 28667 32158 R-404A M3 3.5 5/8 1 1/8 38 200-230/60/3
MHHZ0331CM CS20K6E-TF5 CS20K6E-TF5 19890 25468 28667 32158 R-404A M3 3.5 5/8 1 1/8 38 200-230/60/3
MHHZ033CC CS20K6E-TF5 CS20K6E-TF5 19890 25468 28667 32158 R-404A M3 3.5 1/2 7/8 14.9 200-230/60/3
MHHZ0431B CS27K6E-PFV CS27K6E-PFV 26544 33987 38042 42324 R-404A M5 4 5/8 1 3/8 44 208-230/60/1
MHHZ0431BM CS27K6E-PFV CS27K6E-PFV 26544 33987 38042 42324 R-404A M5 4 5/8 1 3/8 44 208-230/60/1
MHHZ0431C CS27K6E-TF5 CS27K6E-TF5 26189 33532 37491 41708 R-404A M5 4 5/8 1 3/8 44 200-230/60/3
MHHZ0431CM CS27K6E-TF5 CS27K6E-TF5 26189 33532 37491 41708 R-404A M5 4 5/8 1 3/8 44 200-230/60/3
MHHZ043CC CS27K6E-TF5 CS27K6E-TF5 26189 33532 37491 41708 R-404A M5 4 5/8 7/8 19 200-230/60/3
MHHZ0500B CS33K3E-PFV CS33K3E-PFV 40683 45535 50387 R-404A X 5 5/8 1 3/8 44 208-230/60/1
MHHZ0500C CS33K3E-TF5 CS33K3E-TF5 40151 45018 49885 R-404A X 5 5/8 1 3/8 44 200-230/60/3
