CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At Room
Temp. With a 10° TD, 90°
Ambient
Ref.
Base
Size
(See pp.
39-41) H.P.
Connections
MCA
Voltage
20
30
35
40
Liquid
Suction
MHHX0051B ART82C1-IAV-201 ART82C1-CAV-201 3930 5040 5690 6430 R-22 M1 .50 3/8 5/8 10 208-230/60/1
MHHX0075B RS64C2-IAV-201 RS64C2-IAV-201 5570 7300 8280 9350 R-22 M1 .75 3/8 5/8 13 208-230/60/1
MHHX0061B ART69C1-IAV ART69C1-IAV 3846 4826 5383 5996 R-22 M1 .5 3/8 5/8 13 208-230/60/1
MHHX0061BM ART69C1-IAV ART69C1-IAV 3846 4826 5383 5996 R-22 M1 .5 3/8 5/8 13 208-230/60/1
MHHX0061TB ART69C1-IAV ART69C1-IAV 3769 4826 5383 5996 R-22 M1 .5 3/8 5/8 13 208-230/60/1
MHHX006TB ART69C1-IAV ART69C1-IAV 5017 5642 6267 R-22 S .5 3/8 5/8 13 208-230/60/1
MHHX0081B RS47C2-IAV RS47C2-IAV 4644 6010 6749 7531 R-22 M1 .75 3/8 5/8 13 208-230/60/1
MHHX0081BM RS47C2-IAV RS47C2-IAV 4644 6010 6749 7531 R-22 M1 .75 3/8 5/8 13 208-230/60/1
MHHX0081TB RS47C2-IAV RS47C2-IAV 4694 6010 6749 7531 R-22 M1 .75 3/8 5/8 13 208-230/60/1
MHHX008TB RS47C2-IAV RS47C2-IAV 6341 7173 8004 R-22 S .75 3/8 5/8 14 208-230/60/1
MHHX0111B RS70C1-PFV RS70C1-PFV 6248 8119 9116 10151 R-22 M1 1 3/8 5/8 20 208-230/60/1
MHHX0111BM RS70C1-PFV RS70C1-PFV 6248 8119 9116 10151 R-22 M1 1 3/8 5/8 20 208-230/60/1
MHHX0111C RS70C1-TFC RS70C1-TFC 6474 8272 9227 10235 R-22 M1 1 3/8 5/8 20 208-230/60/3
MHHX0111CM RS70C1-TFC RS70C1-TFC 6474 8272 9227 10235 R-22 M1 1 3/8 5/8 20 208-230/60/3
MHHX0151B CR18KQ-PFV CR18KQ-PFV 8829 11305 12864 14511 R-22 M2 1.5 3/8 7/8 19 208-230/60/1
MHHX0151BM CR18KQ-PFV CR18KQ-PFV 8829 11305 12864 14511 R-22 M2 1.5 3/8 7/8 19 208-230/60/1
MHHX0151C CR18KQ-TF5 CR18KQ-TF5 9008 11534 13089 14724 R-22 M2 1.5 3/8 7/8 20 208-230/60/3
MHHX0151CM CR18KQ-TF5 CR18KQ-TF5 9008 11534 13089 14724 R-22 M2 1.5 3/8 7/8 20 208-230/60/3
MHHX0191B CR24KQ-PFV CR24KQ-PFV 10975 14052 15941 17934 R-22 M2 2 1/2 7/8 23 208-230/60/1
MHHX0191BM CR24KQ-PFV CR24KQ-PFV 10975 14052 15941 17934 R-22 M2 2 1/2 7/8 23 208-230/60/1
MHHX0191C CR24KQ-TF5 CR24KQ-TF5 10743 13756 15671 17706 R-22 M2 2 1/2 7/8 23 200-230/60/3
MHHX0191CMC CR24KQ-TF5 CR24KQ-TF5 10743 13756 15671 17706 R-22 M2 2 1/2 7/8 23 200-230/60/3
MHHX0191CC CR24KQ-TF5-240 CR24KQ-TF5-240 11450 14661 16248 17867 R-22 M2 2 1/2 7/8 23 200-230/60/3
MHHX019CCC CR24KQ-TF5-240 CR24KQ-TF5-240 15445 17549 19653 R-22 T 2 1/2 7/8 23 200-230/60/3
MHHX0221B CR28KQ-PFV CR28KQ-PFV 12559 16081 18189 20387 R-22 M2 2.2 1/2 7/8 29 208-230/60/1
MHHX0221C CR28KQ-TF5 CR28KQ-TF5 12034 15408 17500 19711 R-22 M2 2.2 1/2 7/8 29 200-230/60/3
MHHX0251B CR33KQ-PFV CR33KQ-PFV 14383 18416 20714 23059 R-22 M2 2.5 1/2 7/8 38 208-230/60/1
MHHX0251C CR33KQ-TF5 CR33KQ-TF5 14465 18521 20714 23059 R-22 M2 2.5 1/2 7/8 23 200-230/60/3
MHHX0301B CR37KQ-PFV CR37KQ-PFV 18127 23210 26173 29355 R-22 M3 3 1/2 7/8 38 208-230/60/1
MHHX0301BM CR37KQ-PFV CR37KQ-PFV 18127 23210 26173 29355 R-22 M3 3 1/2 7/8 38 208-230/60/1
MHHX0301C CR37KQ-TF5 CR37KQ-TF5 18324 23462 26284 29366 R-22 M3 3 1/2 7/8 32 200-230/60/3
MHHX0301CC CR37KQ-TF5 CR37KQ-TF5 18324 23462 26284 29366 R-22 M3 3 1/2 7/8 32 200-230/60/3
MHHX0301CM CR37KQ-TF5 CR37KQ-TF5 18324 23462 26284 29366 R-22 M3 3 1/2 7/8 32 200-230/60/3
MHHX030CCC CR37KQ-TF5 CR37KQ-TF5 24105 27187 30269 R-22 U 3 1/2 7/8 18 200-230/60/3
MHHX031CCC CR37KQ-TF5 CR37KQ-TF5 18324 23462 26284 29366 R-22 M3 3 1/2 7/8 32 200-230/60/3
MHHX0351B CR41KQ-PFV CR41KQ-PFV 19633 25139 28236 31536 R-22 M3 3.2 1/2 7/8 38 208-230/60/1
MHHX0351C CR41KQ-TF5 CR41KQ-TF5 20010 25621 28611 31779 R-22 M3 3.2 1/2 7/8 32 200-230/60/3
MHHX035CC CR41KQ-TF5 CR41KQ-TF5 20010 25621 28611 31779 R-22 M3 3.2 1/2 7/8 32 200-230/60/3
MHHX0351CC CR41KQ-TF5 CR41KQ-TF5 20010 25621 28611 31779 R-22 M3 3.2 1/2 7/8 32 200-230/60/3
MHHX035CCC CR41KQ-TF5 CR41KQ-TF5 26354 29589 32825 R-22 U 3.2 1/2 7/8 32 200-230/60/3
MHHX0441B CR53KQ-PFV CR53KQ-PFV 26704 34192 38416 42928 R-22 M5 4 5/8 1 1/8 45 208-230/60/1
MHHX0441BM CR53KQ-PFV CR53KQ-PFV 26704 34192 38416 42928 R-22 M5 4 5/8 1 1/8 45 208-230/60/1
MHHX0441C CR53KQ-TF5 CR53KQ-TF5 26925 34476 38676 42992 R-22 M5 4 5/8 1 1/8 44 200-230/60/3
MHHX0441CM CR53KQ-TF5 CR53KQ-TF5 26925 34476 38676 42992 R-22 M5 4 5/8 1 1/8 44 200-230/60/3
MHHX0441CC CR53KQ-TF5 CR53KQ-TF5 26925 34476 38676 42992 R-22 M5 4 5/8 1 1/8 44 200-230/60/3
MHHX044CC CR53KQ-TF5 CR53KQ-TF5 26925 34476 38676 42992 R-22 M5 4 5/8 1 1/8 44 200-230/60/3
MHHX044CCC CR53KQ-TF5 CR53KQ-TF5 35073 39456 43839 R-22 X 4 5/8 1 1/8 45 200-230/60/3
MHHX0501B CRN5-0500-PFV CRN5-0500-PFV 30698 39307 44171 49290 R-22 M5 5 5/8 1 1/8 52 208-230/60/1
MHHX0501C CRN5-0500-TF5 CRN5-0500-TF5 31378 40176 44870 49825 R-22 M5 5 5/8 1 1/8 44 200-230/60/3
MHHX050CC CRN5-0500-TF5 CRN5-0500-TF5 31378 40176 44870 49825 R-22 M5 5 5/8 7/8 44 200-230/60/3
MHHX0501CM CRN5-0500-TF5 CRN5-0500-TF5 31378 40176 44870 49825 R-22 M5 5 5/8 1 1/8 44 200-230/60/3
MHHXT181B AWG5520EXN AWG5520EXN 11120 14238 16188 18137 R-22 M2 1.5 3/8 7/8 23 208-230/60/1
MHHXT181C AWG5520EXT AWG5520EXT 11120 14238 16188 18137 R-22 M2 1.5 3/8 7/8 23 200-230/60/3
