CONDENSING UNIT SPECIFICATIONS
Master-Bilt
®
Model
Cond Unit/Comp
Model
Model
10° TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41)
HP
Connections
MCA Voltage 35 40
Liquid Suction
BCHX0050B E3AH-A050-CAV HAG2-0050-CAV 4059 4510 R-22 A .5 3/8 5/8 7 208-230/60/1
BCHX0070B E3AH-A075-CAV KAE2-0075-CAV 6084 6760 R-22 A .75 3/8 5/8 8 208-230/60/1
BCHX0070C E3AH-A075-TAC KAN1-0075-TAC 6084 6760 R-22 A .75 3/8 5/8 6 208-230/60/3
BCHX0070CC
E3AH-A075-TAC KAN1-0075-TAC 6084 6760 R-22 A .75 3/8 5/8 6 208-230/60/3
BCHX0100B E3AH-A100-CAV KAR2-0100-CAV 8064 8960 R-22 A 1 3/8 5/8 11 208-230/60/1
BCHX0100C E3AH-A100-TAC KAR1-0100-TAC 8064 8960 R-22 A 1 3/8 5/8 7 208-230/60/3
BCHX0100E E3AH-A100-TAD KAR1-0100-TAD 8064 8960 R-22 A 1 3/8 5/8 5 460/60/3
BCHX0150B KAGB-0150-CAV KAGB-0150-CAV 11197 12441 R-22 B 1.5 3/8 5/8 15 208-230/60/1
BCHX0150C KAGA-0150-TAC KAGA-0150-TAC 11197 12441 R-22 B 1.5 3/8 5/8 10 208-230/60/3
BCHX015XC KAGA-0150-TAC KAGA-0150-TAC 11197 12441 R-22 B 1.5 3/8 5/8 10 208-230/60/3
BCHX015YC KAGA-0150-TAC KAGA-0150-TAC 11197 12441 R-22 C 2 1/2 7/8 11 230/60/1
BCHX0200B ERC2-0200-CAB ERA2-0200-CAB 15813 17570 R-22 C 2 1/2 7/8 17 230/60/1
BCHX0200C ERC1-0200-TAC ERA1-0200-TAC 15813 17570 R-22 C 2 1/2 7/8 12 208-230/60/3
BCHX0200E ERA1-0200-TAD ERA1-0200-TAD 15813 17570 R-22 C 2 1/2 7/8 7 460/60/3
BCHX0200G ERA1-0200-TAD ERA1-0200-TAD 13178 14642 R-22 C 2 1/2 7/8 7 380/420/50/3
BCHX0300B ERF2-0310-CAB ERF2-0310-CAB 26000 28889 R-22 C 3 5/8 1 1/8 25 230/60/1
BCHX0300C ERF1-0311-TAC ERF1-0310-TAC 26000 28889 R-22 C 3 5/8 1 1/8 19 208-230/60/3
BCHX0300E ERF1-0310-TAD ERF1-0310-TAD 26000 28889 R-22 C 3 5/8 1 1/8 10 460/60/3
BCHX030LC ERF1-0310-TAC ERF1-0310-TAC 27019 30021 R-22 C 3 5/8 1 1/8 19 208-230/60/3
BCHX0500C 2DC3-050E-TFC 2DC3-050E-TFC 39576 43973 R-22 C 5 5/8 1 3/8 34 208-230/60/3
BCHX0500E 2DC3-050E-TFD 2DC3-050E-TFD 41437 46041 R-22 C 5 5/8 1 3/8 16 460/60/3
BCHX050LC 2DC3-050E-TFC 2DC3-050E-TFC 42017 46685 R-22 D 5 5/8 1 3/8 34 208-230/60/3
BCHX050XC 2DD3-050E-TFC 2DD3-050E-TFC 51948 57720 R-22 D 5 5/8 1 3/8 34 208-230/60/3
BCHX0750C 2DA3-075E-TFC 2DA3-075E-TFC 70260 78067 R-22 E 7.5 5/8 1 3/8 47 208-230/60/3
BCHX0750E 2DA3-075E-TFD 2DA3-075E-TFD 70260 78067 R-22 E 7.5 5/8 1 3/8 21 460/60/3
BCHX075LC 2DA3-075E-TFC 2DA3-075E-TFC 74515 82794 R-22 F 7.5 7/8 1 3/8 64 208-230/60/3
BCHX075VCC
2DA3-075E-TFC 2DA3-075E-TFC 70260 78067 R-22 E 7.5 5/8 1 3/8 47 208-230/60/3
BCHX075YC 2DA3-075E-TFC 2DA3-075E-TFC 70260 78067 R-22 E 7.5 5/8 1 3/8 47 208-230/60/3
BCHX1000C 3DB3-100E-TFC 3DB3-100E-TFC 102088 113431 R-22 F 10 7/8 1 3/8 64 208-230/60/3
BCHX1000E 3DB3-100E-TFD 3DB3-100E-TFD 102088 113431 R-22 F 10 7/8 1 3/8 30 460/60/3
BCHX1200C 3DF3-1200-TFC 3DF3-1200-TFC 116055 128950 R-22 F 12 7/8 1 3/8 70 208-230/60/3
BCHX1500C 3DS3-150E-TFC 3DS3-150E-TFC 128702 143002 R-22 F 15 7/8 1 5/8 84 208-230/60/3
BCHX1500E 3DS3-150E-TFD 3DS3-150E-TFD 128702 143002 R-22 F 15 7/8 1 5/8 42 460/60/3
BCHX2000C 4DA3-200E-TSK 4DA3-200E-TSK 153092 170102 R-22 P 20 1 3/8 2 1/8 97 208-230/60/3
BCHX2000E 4DA3-200E-TSK 4DA3-200E-TSK 153092 170102 R-22 P 20 1 3/8 2 1/8 56 460/60/3
BCHX2500C 4DH3-2500-TSK 4DH3-2500-TSK 196176 217973 R-22 P 25 1 3/8 2 1/8 118 208-230/60/3
BCHX2500E 4DH3-2500-TSK 4DH3-2500-TSK 196176 217973 R-22 P 25 1 3/8 2 1/8 59 460/60/3
BCHX3000C 4DJ3-3000-TSK 4DJ3-3000-TSK 232187 257985 R-22 R 30 1 3/8 2 1/8 140 208-230/60/3
BCHX3000E 4DJ3-3000-TSK 4DJ3-3000-TSK 232187 257985 R-22 R 30 1 3/8 2 1/8 70 460/60/3
BCHX3500C 6DH3-3500-TSK 6DH3-3500-TSK 275792 306435 R-22 R 35 1 5/8 2 1/8 156 208-230/60/3
BCHX3500E 6DH3-3500-TSK 6DH3-3500-TSK 275792 306435 R-22 R 35 1 5/8 2 1/8 78 460/60/3
BCHX4000C 6DJ3-4000-TSN 6DJ3-4000-TSN 336116 373462 R-22 R 40 1 5/8 2 1/8 200 230/60/3
BCHX4000E 6DJ3-4000-TSN 6DJ3-4000-TSN 336116 373462 R-22 R 40 1 5/8 2 1/8 100 460/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
