CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a
10° TD, 90° Ambient
Ref.
Size
(See
pp.
39-41)
H.P.
Connections
MCA Voltage
30 35
40
Liquid
Suction
MCHX0061B HAG2-0050-CAV HAG2-0050-CAV 3947 4441 4965 R-22 M1 .5 3/8 5/8 13 208-230/60/1
MCHX0081B KAN2-0075-CAV KAN2-0075-CAV 5860 6561 7301 R-22 M1 .75 3/8 5/8 13 208-230/60/1
MCHX0081C KAN1-0075-TAC KAN1-0075-TAC 5757 6501 7297 R-22 M1 .75 3/8 5/8 13 208-230/60/3
MCHX0111B KAR2-0100-CAV KAR2-0100-CAV 8058 8954 9875 R-22 M1 1 3/8 5/8 19 208-230/60/1
MCHX0111C KAR1-0100-TAC KAR1-0100-TAC 7828 8676 9556 R-22 M1 1 3/8 5/8 19 208-230/60/3
MCHX0151B KAGB-0150-CAV KAGB-0150-CAV 10529
11836
13264
R-22 M2 1.5 3/8 7/8 23 208-230/60/1
MCHX0151C KAGA-0150-TAC KAGA-0150-TAC 10753
11989
13325
R-22 M2 1.5 3/8 7/8 19 208-230/60/3
MCHX0191B ERA2-0200-CAB ERA2-0200-CAB 13173
15256
17317
R-22 M2 2 1/2 7/8 23 230/60/1
MCHX0191C ERA1-0200-TAC ERA1-0200-TAC 13173
15256
17317
R-22 M2 2 1/2 7/8 23 208-230/60/3
MCHX0301B ERF2-0310-CAB ERF2-0310-CAB 24490
27290
30343
R-22 M3 3 1/2 7/8 38 230/60/1
MCHX0301C ERF1-0310-TAC ERF1-0310-TAC 24455
27094
29985
R-22 M3 3 1/2 7/8 32 208-230/60/3
MCHX0441C NRB2-0400-TFC NRB2-0400-TFC 34517
38943
43539
R-22 M5 4 5/8 1 1/8 44 208-230/60/3
MCHX0501C NRA2-0500-TFC NRA2-0500-TFC 40155
44944
49973
R-22 M5 5 5/8 1 1/8 44 208-230/60/3
MCHZ0061B HAJB-005E-CAV HAJB-005E-CAV 5026 5505 5983 R-404A
M1 .5 3/8 5/8 13 208-230/60/1
MCHZ0071C KANA-007E-TAC KANA-007E-TAC 6270 6894 7518 R-404A
M1 .75 3/8 5/8 13 208-230/60/3
MCHZ0081B KANB-007E-CAV KANB-007E-CAV 6270 6894 7518 R-404A
M1 .75 3/8 7/8 13 208-230/60/1
MCHZ0111B KARB-010E-CAV KARB-010E-CAV 8542 9214 9886 R-404A
M1 1 3/8 7/8 19 208-230/60/1
MCHZ0111C KARA-010E-TAC KARA-010E-TAC 8301 9211 10121
R-404A
M1 1 3/8 7/8 19 208-230/60/3
MCHZ0181B KAKB-021E-CAV KAKB-021E-CAV 14862
16578
18293
R-404A
M2 2 1/2 1 1/8 23 230/60/1
MCHZ0211C KAKA-020E-TAC KAKA-020E-TAC 14461
15865
17268
R-404A
M2 2 1/2 7/8 23 208-230/60/3
MCHZ0221C ERCA-021E-TAC ERCA-021E-TAC 18348
20165
21983
R-404A
M2 2 1/2 1 1/8 23 208-230/60/3
MCHZ0251C ERCA-021E-TAC ERCA-021E-TAC 18348
20165
21983
R-404A
M2 2 1/2 7/8 23 208-230/60/3
MCHZ0311C ERFA-031E-TAC ERFA-031E-TAC 26560
29326
32093
R-404A
M3 3 1/2 7/8 32 208-230/60/3
MCHZ0321B ERFB-031E-CAB ERFB-031E-CAB 26101
28803
31506
R-404A
M3 3 5/8 1 1/8 38 230/60/1
MCHZ0321C ERFA-031E-TAC ERFA-031E-TAC 26560
29326
32093
R-404A
M3 3 5/8 1 1/8 32 208-230/60/3
MCHZ0461C NRB2-040E-TFC NRB2-040E-TFC 36991
41091
45191
R-404A
M5 4 5/8 1 3/8 44 208-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
