Component Replacement
Padlock Service Manual 2–3
11B parts list Refer to Figure 2.1 and the table below to find the part that you need.
Item Part No. Qty. Description
1
not shown
not shown
not shown
not shown
not shown
not shown
not shown
not shown
not shown
C26195
C26197
C26199
C26203
C26194
C26196
C26198
C26202
C26250
C26249
1
1
1
1
1
1
1
1
1
1
Stainless steel shackle for 3/4″ opening
*
Stainless steel shackle for 1 1/2″ opening
Stainless steel shackle for 2″ opening
Stainless steel shackle for 4″ opening
Bronze shackle for 3/4″ opening
Bronze shackle for 1 1/2″ opening
Bronze shackle for 2″ opening
Bronze shackle for 4″ opening
Frangible shackle for 1 1/2″ opening
Frangible shackle for 4″ opening
* The length of the shackle opening is measured from the top of the case to the inside of
the shackle when the padlock is locked.
2 A26193 1 Shackle spring
3 C26179
A26265
C26175
A26252
1
1
1
1
Standard case
Double lockout case for chain (indicated by dashed
lines)
Double lockout case (indicated by dashed lines)
Case for chain
4 A26255 1 Clevis rivet
5 B26261 1 Clevis
6
not shown
A21417
A21420
1
1
M1 Chain [there is no distinction between length
and bulk for M1 chain like the M5 chain]
M5 Chain – 9 inch
†
† To order M5 bulk chain use part number A23121 and specify the length.
7 A26192 2 Tumbler
8 B26187 1 Locking cam assembly
9
not shown
A26177
A26185
1
1
Key retained throw member
Non-key retained throw member
not shown A06831
‡
‡ One needed for 6-pin core. Two needed for 5-pin core.
Spacer (For 6-pin or 5-pin core only)
not shown B70146 1 Colored O.S.H.A. cover
**
** When ordering the O.S.H.A. cover, indicate color: red; yellow; blue; black; orange; or
green.
not shown C26517 1 Weather cover
