Component Replacement
Padlock Service Manual 2–11
41B parts list Refer to Figure 2.5 and the table below to find the part that you need.
Item Part No. Qty. Description
1
not shown
not shown
not shown
not shown
not shown
not shown
not shown
not shown
not shown
not shown
not shown
C26227
C26229
C26231
C26235
C26226
C26228
C26230
C26234
C26544
C26545
C26546
C26547
1
1
1
1
1
1
1
1
1
1
1
1
Stainless steel shackle for 3/4″ opening
*
Stainless steel shackle for 1 1/2″ opening
Stainless steel shackle for 2″ opening
Stainless steel shackle for 4″ opening
Bronze shackle for 3/4″ opening
Bronze shackle for 1 1/2″ opening
Bronze shackle for 2″ opening
Bronze shackle for 4″ opening
Cut-resistant shackle for 3/4″ opening
Cut-resistant shackle for 1 1/2″ opening
Cut-resistant shackle for 2″ opening
Cut-resistant shackle for 4″ opening
* The length of the shackle opening is measured from the top of the case to the inside of
the shackle when the padlock is locked.
2 A26193 1 Shackle spring
3 not shown
not shown
not shown
not shown
not shown
C26262
A26254
A26266
C26161
C26181
1
1
1
1
1
Cutaway padlock case
Case for clevis and chain
Car seal case for chain
Car seal case
Standard case
4 A26257 1 Clevis rivet
5 B26261 1 Clevis
6
not shown
A21417
A23120
1
1
M1 Chain
M5 Chain – 9 inch
†
† To order M5 bulk chain use part number A23121 and specify the length.
7 A26192 2 Tumbler
8 B26187 1 Locking cam assembly
9
not shown
A26177
A26185
1
1
Key retained throw member
Non-key retained throw member
not shown A06831
‡
‡ One needed for 6-pin core. Two needed for 5-pin core.
Spacer (For 6-pin or 5-pin core only)
not shown B70148 1 Colored O.S.H.A. cover
**
** When ordering the O.S.H.A. cover, indicate color: red; yellow; blue; black; orange; or
green.
not shown C26519 1 Weather cover
