Stanley 3 Series User Manual

Component Replacement
Padlock Service Manual 2–13
11B Frangible
Shackle Kit
parts list
Refer to Figure 2.6 and the table below to find the part that you need.
Chains
parts list
Refer to Figure 2.7 and the table below to find the part that you need.
Lubricant
parts list
Refer to Figure 2.8 and the table below to find the part that you need.
Item
*
* These parts can be ordered as a kit by indicating part number is B26290.
Part. No. Qty. Description
1 C26249 3 Shackle
2 A26193 3 Shackle spring
3 A26270 1 Disassembly tool
Item Part No. Description
1 A21417 M1 Bronze chain
2 A23120 M5 Galvanized steel chain with gray plastic polycoat covering –
9 inch (10 links)
not
shown
A23121 M5 Galvanized steel chain with gray plastic polycoat covering –
bulk; specify length
Item Nomenclature Description
1 BD660 Corrosion Free Formula 8000 Industrial Lubricant
