Component Replacement
Padlock Service Manual 2–9
21JB parts list Refer to Figure 2.4 and the table below to find the part that you need.
Item Part No. Qty. Description
1 B26209
*
* The cable assembly number is determined by the length of the cable ordered. When
ordering, indicate number B26209 followed by a dash and the length of the cable in
inches.
1Cable assembly
2 A26193 1 Shackle spring
3 C26180 1 Standard case
4 B26289 1 Locking cam assembly
5 A26192 2 Tumbler
6 A26177 1 Key retained throw member
not shown A06831
†
† One needed for 6-pin core. Two needed for 5-pin core.
Spacer (For 6-pin or 5-pin core only)
