Stanley 3 Series User Manual

Component Replacement
Padlock Service Manual 2–7
21B shrouded
parts list
Refer to Figure 2.3 and the table below to find the part that you need.
Item Part No. Qty. Description
1
C81133
1
Cut-resistant shackle
2 C81131 1 Shroud
3 A26268 1 Case
4 A26257 1 Clevis rivet
5 A26192 2 Tumbler
6 B26187 1 Locking cam assembly
7
not shown
A26177
A26185
1
1
Key retained throw member
Non-key retained throw member
8 A81136 1 Rubber spacer
not shown A06831
*
* One needed for 6-pin core. Two needed for 5-pin core.
Spacer (For 6-pin or 5-pin core only)
