This appliance conforms to the following:
Low Voltage Equipment: 72/23/EEC
95/68/EEC
Electromagnetic Compatibility: 89/336/EEC
92/31/EEC
93/68/EEC
OPERATION
PRE-OPERATIONAL CHECKS
(a) Check that the cooker is connected to the mains
electrical supply.
“WARNING THIS EQUIPMENT MUST BE
EARTHED”
(b) Check that all valves in the oil line are open and
that the filter and oil pump are purged of air.
(c) Check that appliance thermostats are in the off
position.
(d) Check that the boiler and heating system is full
of water and purged of air.
BURNER SPECIFICATION
BOILER BURNER COOKER BURNER
100K 80K 60K 100K/80K/60K
Burner Input
(kW) Continuous Running 34.2 27.7 21.4 19.5
(kW) Cycling N/A N/A N/A 4.4
(Btu’s) Continuous Running 116,760 94,600 73,000 66,875
(Btu’s) Cycling N/A N/A N/A 14,950
Boiler Output
(kW) Continuous Running 29.3 23.5 17.6 2.1
(kW) Mean Cycling N/A N/A N/A 1.2
(Btu’s) Continuous Running 100,000 80,000 60,000 7,000
(Btu’s) Mean Cycling N/A N/A N/A 4,000
Nozzle 0.85 80
o
S (C.E.N) 0.65 80
o
S (C.E.N) 0.55 80
o
S (C.E.N) 0.5 60
o
S (C.E.N)
Pressure
(Bar) 7.4 7.4 7.1 7.1
(PSI) 107 108 103 110
Fuel Consumption
(L/Hr) Continuous Running 3.6 2.9 2.2 2.1
(L/Hr) Cycling N/A N/A N/A 0.47
US Gal/Hr
Continuous Running 0.95 0.77 0.58 0.55
US Gal/Hr Cycling N/A N/A N/A 0.12
All data are taken under laboratory conditions and may vary in use
Design flow rate through the boiler 38.2 L/min / 8.4 Gpm
Static differential across the boiler 52.4 mbar / 21” wg
Dynamic pressure differential across the boiler 33 mbar / 13.23” wg
Differential Pressure Across the Boiler
Note: Design temperature differential across the boiler = 11°C (20°F)
4
