Stanley MODEL 1 - Page 103

5-9
Maintenance
5
2
Pull the upper fitting of the filter, and it will detach from the printer.
3
Gently pull the filter to separate from printer.
4
As shown below, slightly hang the lower half of the filter and gently push the top side to click it in.
5
Fasten the screw using a Phillips screwdriver.
