5
Pull the nozzle component to detach.
NOZZLE
Assembling the Nozzle
Initiate process ONLY after power of machine is turned OFF, and after all power cables are disconnected.
1
With the cover lifted up attach the nozzle.
The Nozzle attaches with magnet power, but please make sure that the component is firmly attached.
NOZZLE
2
Insert the 2 connectors and make sure to hear the clicking sound.
CONNECTOR
CONNECTOR
To Next Page
