2
Press the tube holder and pull the tube to remove.
TUBE
TUBE HOLDER
3
Push the hook on the top, and lift open the cover.
HOOK
COVER
4
Push the 2 hooks on the harness connector to disengage the connector.
To remove the left hand side connector, press on the hook until you hear a click sound.
Then you can safely disconnect.
CONNECTOR
CONNECTOR
To Next Page
