Stanley MODEL 1 - Page 107

5-13
Maintenance
5
3
Push the cover down and make sure to hear the clicking sound.
COVER
Please be careful not to position the harness near the left, right and center section of the cover.
The harness can get caught in between covers when closing.
Caution Harness
4
Insert Tube.
Note
- Push the tube in about 50mm until the tube under the black indicator cannot be seen.
TUBE
