Stanley MODEL 1 - Page 108

Maintenance
5-14
5
5
Slightly lifting the tube and insert the Snap-Ring.
Insert the Snap-Ring in between the Fitting and Holder.
SNAP-RING
SNAP-RING
INSERTION
POINT
6
Finally, push tube in all the way through.
- Approximately 1.5mm can be additionally inserted.
TUBE
7
Use the “CARTRIDGE-LOAD” command to finish the cartridge loading process.
