<Interior>
3
1
2
1
4
No. Part Name Description
1 Bed height adjustment Knob Used to level the aluminum bed.
2 Removable bed handle Used to assemble and dismantle aluminum bed
3 Bed heater Heats the printables' bottom surface to stabilize it on the bed.
4 Aluminum bed (bed sheet) Seating space for Printable
1
<Nozzle>
2
6
4
3
5
No. Part Name Description
1 Body Main body of the nozzle part.
2 Fan 1 Cooling fan for extrusion.
3 Fan 2 Cooling fan for Nozzle heatsink.
4 Nozzle Nozzle for printing.
5 Heater block Nozzle part for filament heating.
6 Levelling sensor Sensor for bed levelling sensor.
