Page #13 background imageLoading...
Page #13 background image
2.3. Main components list
ref g. 1 & 2
Nr. in In-
struction
Manual
Desctription
Thread
metric
Re-order
Spare part nrs.
Metric
Thread
Imperial
Re-order
Spare part nrs.
Imperial
QTY
M4 07555-09004 8 UNC 07555-09058 1
1 Mandrel
M5 07555-09005 10 UNF 07555-09070 1
M 6 07555-09006 1/4“ UNC 07555-09048 1
M8 07555-09008 5/16“ UNC 07555-09040 1
2 Nose Tip
M4 07555-00904 8 UNC 07555-00858 1
M5 07555-00905 10 UNF 07555-00850 1
M6 07555-00906 1/4“ UNC 07555-00848 1
M8 07555-00908 5/16“ UNC 07555-00840 1
3 Lock Nut - 07555-00901 1
4 Nose Casing - 74202-02021 1
5 Chuck Nut - 74202-02022 1
6 Reducing Sleeve
M4 07555-09104 8 UNC 07555-09158 1
M5 07555-09105 10 UNF 07555-09150 1
M6 07555-09106 1/4“ UNC 07555-09148 1
M8 07555-09108 5/16“ UNC 07555-09140 1
7 Drive Shaft
M4 07555-01004 8 UNC 07555-00758 1
M5 07555-01005 10 UNF 07555-00750 1
M6 07555-01006 1/4“ UNC 07555-00748 1
M8 07555-01008 5/16“ UNC 07555-00740 1
8 Mandrel Adaptor - 74202-02023 1
9 Nose Rod - 74202-02039 1
10 Suspension Ring - 74202-02012 1
11 End Cap Assembly - 74202-02107 1
12 Stroke Indication Markings - - -
13 Stroke Locking Pin - 74202-02095 1
14 Stroke Setter - 74202-02010 1
15 Stroke Setter Recess - - -
16 Air Inlet Assembly - 74202-12700 1
17 Manual Reverse Trigger - 74202-02030 1
18 Regulator Lock - 74202-02038 1
19 Pressure Regulator - 74202-02037 1
20 Trigger - 74202-02020 1
21 Pin Punch - 07900-00624 1
Metric Imperial
Complete nose assembly
M4 07555-09884 8 UNC 07555-09858
M5 07555-09885 10 UNF 07555-09870
M6 07555-09886 1/4“ UNC 07555-09848
M8 07555-09888 5/16“ UNC 07555-09840
* All sizes are supplied with Lock Nut (3) 07555-00901.
For additional sizes please visit www.StanleyEngineeredFastening.com
11
ENGLISH
