6. Servicing the Tool
Regular servicing must be carried out by trained personnel and a comprehensive inspection performed
annually or every 500,000 cycles, whichever is sooner.
Cleaning and Maintenance
DISCONNECT AIR SUPPLY
Nose assemblies should be serviced at weekly intervals or every 5,000 cycles
CAUTION - Blow dirt and dust out of the main housing with dry air as often as dirt is seen collecting in and
around the air vents where the Pneumatic Cylinder connects to the plastic Handle Assembly. Wear approved
eye protection and approved dust mask when performing this procedure.
CAUTION - Never use solvents or other harsh chemicals for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
CAUTION - Before maintenance, remove any dangerous substances that may have accumulated due to work
processes.
• Disconnect the air supply
• Remove the complete nose assembly using the reverse procedure to the Fitting Instructions page 12 (4.1).
• Any worn or damaged part must be replaced by a new part.
• Particularly check wear on Mandrel.
• Assemble according to tting instructions.
6.1 Daily Servicing
• Check for air leaks. If damaged, hoses and couplings must be replaced by new items.
• Check that the Nose Assembly is correct and tted properly.
• Check if the stroke of the tool is adequate to place selected Blind Rivet Nut. See Stroke Adjustment
page14 (4.3.1.).
• Inspect the Mandrel 1 in the nose assembly for wear or damage. If any, replace.
6.2 Weekly Servicing
Maintenance Kit 07900-09301
Part Number Description Qty
07900-00624 4mm Pin Punch 1
07900-00632 17mm/19mm Spanner 1
07900-00225 5mm Hexagonal Wrench 1
• Check for oil leaks and air leaks on air supply hose and ttings and tool.
• With the tool laid horizontally, open “Oil Plug” and check oil level, if low re-prime, refer to “Service manual,
Section 6”.
• Check the stroke actuation of the tool and compare with the setting of the Stroke indication markings 12.
If the stroke is not achieved, grease the return spring as necessary. Ref. Service Manual, section 6.
For full servicing, troubleshooting and maintenance instructions please refer to Service Manual 07900-09302.
6.3 Protecting the environment
Assure conformity with applicable disposal regulations. Dispose all waste products at an approved waste
facility or site so as not to expose personnel and the environment to hazards.
16
ENGLISH
