SAFETY EDGES
SAFETY EDGESSAFETY EDGES
SAFETY EDGES
The cabin lift has safety edges fitted to protect the user from moving parts of the lift.
The protection is provided by two different methods:
Light curtain protection
Light curtain protectionLight curtain protection
Light curtain protection
This is provided by sensors fitted on the vertical plane of the lift
entrances. If interrupted during travel, the lift will stop moving until the
obstruction is cleared. This is also indicated identified by the lift voice
advising the user to move away from the obstruction.
Mechanical safety edge
Mechanical safety edgeMechanical safety edge
Mechanical safety edge
This is provided by a metal strip at the bottom and top of the lift
entrance. If depressed during lift travel the lift will stop moving until the
obstruction is cleared.
IN THE EVENT OF POWER LOSS TO THE LIFT
IN THE EVENT OF POWER LOSS TO THE LIFTIN THE EVENT OF POWER LOSS TO THE LIFT
IN THE EVENT OF POWER LOSS TO THE LIFT
During power loss the lift will revert to a battery back up supply fitted on the lift. This battery
will maintain the power to the emergency platform lighting, buttons, Digital display and
door locking. If fully charged it will do this for one hour.
If the user is at landing the door can be unlocked by pressing the button of the floor that the
lift cabin is located.
MI D I LI F T X LP L U S C A B I
MI D I LI F T X LP L U S C A B IMI D I LI F T X LP L U S C A B I
MI D I LI F T X LP L U S C A B I N L I F T
N L I FTN L I FT
N L I FT
