– 5 –
3-2. Connecting to a Peripheral Unit
You can connect a peripheral unit to the printer using a modular plug. e following de-
scribes how to install the ferrite core and make the actual connection. See “Modular plug” on
page 25 for details about the type of modular plug that is required. Note that this printer does
not come with a modular plug or wire, so it is up to you to obtain one that suits your needs.
CAUTION
Make sure that the printer is turned o and unplugged from the AC outlet and that the computer
is turned o before making connections.
(1) Connect the peripheral drive cable to the connector on the rear panel of the printer.
CAUTION
Do not connect a telephone line into the peripheral drive connector. Failure to observe this may
result in damage to the printer.
Also, for safety purposes, do not connect wiring to the external drive connector if there is a chance
it may carry peripheral voltage.
To Next Page
