9 Reader Maintenance
9.1 External Grounding Point
The Procyon UHF integrated reader has an external grounding point on the enclosure. For installations
that require external grounding, the user can connect the grounding wire to the enclosure as shown
below:
9.2 Electrostatic Discharge
Use proper Electrostatic Discharge (ESD) precautions to avoid static discharge when handling or
making connections to the Procyon’s communication ports. Equipment failure can result if the
communication ports are subjected to ESD.
9.3 Disconnecting The Reader
When disconnecting the reader, the user should first disconnect the PoE Ethernet connector. Follow
the instructions as shown below:
Unlock the 1st stage cable shield
from reader’s connector by turning
it anti-clockwise along the thread.
To Next Page
