Procyon Reader User Manual
Revision 1.3
Last modified: 02/09/2015
45 | P a g e
10.7 Antenna Specifications
Antenna Option
8 dBi
Polarization
RHCP
Frequency options
865 - 868 MHz
902 - 928 MHz
H Beam Width
90°
V Beam Width
90°
Dimension
216 x 216 x 25 mm
Weight
1.2 kg
Material
UV Protected ABS
Rated Wind Velocity
216 km/h
Mounting Ø
Ø40~Ø60 mm
Antenna Option
12 dBi
Polarization
Linear or RHCP
Frequency options
865 - 868 MHz
902 - 928 MHz
H Beam Width
40°
V Beam Width
40°
Dimension
450 x 450 x 42.5 mm
Weight
1.8 kg
Material
UV Protected ABS
Rated Wind Velocity
216 km/h
Mounting Ø
Ø40~Ø60 mm
10.8 Mechanical Dimensions
The Procyon is available in the following three options:
 8 dBi RHCP
 12 dBi RHCP
 12 dBi Linear or RHCP
The enclosure dimensions for the 8 dBi and 12 dBi antenna options are different. The next two
sections describe the enclosure dimensions for each.
All measurements are in millimetres.
