Procyon Reader User Manual
Revision 1.3
Last modified: 02/09/2015
44 | P a g e
10 Specifications
10.1 RF Specifications
Frequency Range
FCC: 902 - 928 MHz
India: 865 - 867 MHZ
RF Output Power
10 - 30 dBm (conducted)
10.2 Physical Specifications
Operating Temperature
-20°C to 70°C
Storage Temperature
-40°C to 85°C
Dimension
(8 dBi) 220 x 220 x 120 mm
(12 dBi) 450 x 450 x 140 mm
Weight
(8 dBi antenna option) 1.7 kg
(12 dBi antenna option) 2.3 kg
IP Rating
66
10.3 Power Specifications
Power Supply
5V, max 1.5A through PoE IEEE 802.3af
10.4 Ethernet Specifications
Ethernet
10/100 BaseT
Supported cable
Category 5e
10.5 Digital I/O Specifications
Input
5 Vdc, 500 mA
Output
Maximum 24Vdc, 1A / 120 Vac 0.5A
10.6 RS-232 Specifications
Baud rate
9600
Parity
None
Data bits
8
Stop bits
1
