1.2 External Appearance and Part Names
COM1(Serial 6P)
For connecting to the host device
For connecting to a PIN pad or RFID module
COM2(NFC/PED 8P)
Cover Open Lever
ERROR Lamp
POWER Lamp
FEED Button
MODE Button
Printer Cover
LCD
Mechanism
Platen
Platen Gear
Power Inlet for Charging
Power Switch
Thermal Print Head
* The LCD is covered with a protective lm.
Remove the lms if you do not need them.
