Star SM-S220I SERIES - Loading Paper

- 9 -
2.3 Loading Paper
Refer to chapter 4, “Paper” (page 20), to select roll paper that conforms to the specications.
1. Turn on the printer.
2. Put your nger on the lever for opening the cover, and then open and raise the printer cover.
3. Load the roll paper in the orientation shown in the gure below, and then pull the end of the roll
straight toward you.
OFF ON
Cover Open Lerver
Printer Cover
