2. Setup
2.1 Battery Pack
2.1.1 Inserting into the Printer
1. Make sure that the printer has been turned o before you insert or remove the battery pack.
2. Insert the battery pack into the back of the printer as in the gure shown below, following the direc-
tion of the arrow.
3. To remove the battery back, pull back the hook, and use the opposite procedure from the one you
used to insert the battery pack.
4. The battery pack install into External Battery Cradle.
Insert the battery pack in the direction of the arrow.
OFF ON
Push the battery pack until the
hock clicks into place.
Hook
