Camera
Control
COM
360-00230
Network
StarLeaf
Controller Only
Video Out
Camera In
Link/Act
Gigabit Link/Act Gigabit
Mic In
Computer In DVI-I
DC 48V
USB
Line Out
Line In
3330 Group Telepresence
Microphone
(XLR cable)
Telepresence screen 2 Telepresence screen 1
(Optional)
PC video-out
(Optional)
Network
PC audio-out
(Optional)
Camera
(either the supplied PTZ or USB camera)
Power
or
HDMI
+
B A
Configuration
To configure audio, display, and other settings,
go to https://portal.starleaf.com
The selector on the rear of the PTZ camera
must be correctly set. Refer to the camera
documentation, or to the GT Mini documentation
on www.starleaf.com
Power supply
for camera
PTZ camera
control (VISCA In)
PTZ camera
video-out
USB camera
video-out
Amplifier and loudspeakers
(Optional)
StarLeaf Touch 2035
To Next Page
